Hikvision 60W PoE injector

Part Code: HIK-60W-POE-INJ

This product is no longer available. Please browse the website for alternatives or contact our Sales Team for assistance.

Hikvision POE midspan is designed to extract power from a conventional twisted pair Category 5 Ethernet cable, conforming to the IEEE 802.3at Power-over-Ethernet (PoE) standard. The converter signature and control circuit provides the PoE compatibility signature and power classification required by the Power Sourcing Equipment (PSE) before applying up to 60W power to the port.

  • RoHS compliant
  • Compatible With All IEEE pre 802.3af, 802.3at and Legacy Powered Devices
  • Input voltage:90Vac~264Vac
  • Input Frequency: 50/60Hz
  • Support 300Vac input for long time work
  • Output over current protection
  • Short circuit protection
  • MTBF ≥1,000,000 hrs
  • Surge protection
  • CE mark
  • WEEE compliant
Transmission standard Fast Ethernet
Max. PoE power 60 W
Number of ports PoE 1
Voltage type AC
Primary voltage 240...240 V
Frequency 50...60 Hz
Width 70.8 mm
Height 37 mm
Depth 185 mm

Key Features

  • Transmission standard: Fast Ethernet
  • Max. PoE power: 60 W
  • Number of ports PoE: 1
  • Voltage type: AC
  • Primary voltage: 240...240 V
  • Frequency: 50...60 Hz
