Excel CW1308 20 Pair Internal Telephone Cable LSF Per Metre Black

Part Code: TC020PB

Excel multipair internal telephone cables are manufactured in accordance with BT type CW1308. These cores are twisted into pairs and the required number are sheathed together to form the cable. These cores are twisted into pairs and the required number are sheathed together to form the cable. For 32 pair and above cables, groups of pairs, are bundled together for ease of identification.

The print legend on the cable now includes information regarding the DOP number, Test and Classification of the cable for traceability.

Diameter of conductor 0.5 mm
Conductor category Class 1 = solid
Total number of cores 40
Stranding element Pairs
Core insulation Polyvinyl chloride (PVC)
Core identification Colour + rings
Overall screening None
Pair grouping identification Bundles and layers
Conductor screening None
Protective sheath None
Outer sheath material Polyvinyl chloride (PVC)
Outer sheath colour Black
Reaction-to-fire class according to EN 13501-6 Eca
Outer diameter approx. 11.4 mm
Category Voice

Key Features

  • Choice of reel sizes
  • Choice of colours
  • LSF outer sheath
  • 0.5 mm conductor size
  • 25 Year system warranty
  • CIBSE TM65 Embodied Carbon: 0.709 kg CO2e
